Zinga Spin-On Filters provide contaminant removal options and are commonly used on return line low-pressure applications and in some pump suction applications. Zinga Spin-On Filters also offer the added benefit of easy change-out and reduced system downtime.

Zinga Spin-On Filters can be found in mowers, tow trucks, truck-mounted aerial lifts and cranes, pavers, compactors, wood splitters and chippers, trenchers and utility terrain vehicles (UTVs). Spin-on filters are used as process and safety filters to protect individual pumps, valves or the entire hydraulic circuit from contamination as measured per ISO 4406. Spin-on filters are available with cellulose, fiberglass or wire mesh elements, with pressure ranges up to 250 PSI.

In-line spin-on filters can be used for the following purposes:

  • Suction filters
  • On the return circuit, for mounting on the line or on the tank cover
  • In-line for low and medium pressure applications

For Use with BF Series Filter Heads

Diameter: 3.1”

Mounting Thread: 3/4” – 16 UN

Overall Height: 3.4”

Operating Pressure: 200 PSI Max. Operating

∆Pmax Cellulose: 50 PSID without by-pass valve

Temperature: Up to +250°F Operating

Applications: Petroleum-based fluids

For Use with ZAF  Series Filter Heads

Diameter: 3.8”

Mounting Thread: 1” – 12 UN

Operating Pressure: 250 PSI Max. Operating

∆Pmax: 50 PSID

Temperature: Up to +250°F Operating

Applications: Petroleum-based fluids

For Use with ZAF 05, 07 or 10 Series Filter Heads

Diameter: 3.8”

Mounting Thread: 1” – 12 UN

Pressure: 250 PSI Max. Operating

∆Pmax: 80 PSID

Temperature: Up to +250°F Operating

Applications: Petroleum-based fluids

For Use with VAF Series Filter Heads

Diameter: 3.7″

Mounting Thread: 1 1/8” – 16

∆Pmax: 50 PSID

Efficiency: ß<4μ(c) = 2 / ß19μ(c) = 75

Can Color / Imprint: White / Blue

Seals: Buna-N Gasket Standard

Caution: Do not use VE Elements on internal combustion engines

For Use with SF, DF, MF, MFT & ZDF Series Filter Heads

Diameter: 5.1”

Mounting Thread: 1 1/2” -16 UN

Pressure: 200 PSI Max. Operating

∆Pmax: 50 PSID

Temperature: Up to +250°F Operating

Applications: Petroleum-based fluids

For Use with SF, DF, MF, MFT & ZDF Series Filter Heads

Diameter: 5.1”

Mounting Thread: 1 1/2” -16 UN

Pressure: 200 PSI Max. Operating

∆Pmax: 80 PSID

Temperature: Up to +250°F Operating

Applications: Petroleum-based fluids

For Use with HF Series Filter Heads

Diameter: 3.7”

Mounting Thread: 1 1/2” – 16 UN

Pressure: 400 PSI Max. Operating

∆Pmax Cellulose: 50 PSID

∆Pmax Z-Glass: 80 PSID

Temperature: Up to +250°F Operating

Applications: Petroleum-based fluids

For Use with DHF Series Filter Heads

Diameter: 3.7”

Mounting Thread: 1 3/8” -12 UN

Pressure: 500 PSI Max. Operating

∆Pmax Cellulose: 80 PSID

∆Pmax Z-Glass: 100 PSID

Temperature: Up to +250°F Operating

Applications: Petroleum-based fluids
