VE-10 Series
Spin-On Hydraulic Filter Elements: 1 1/8-16 Thread, Enhanced Cellulose Media
FOR USE WITH VAF SERIES FILTER HEADS
The VE-10 Series spin-on filter elements feature a unique 1 1/8-16 mounting thread and compact 5.2-inch height, making them ideal for space-constrained hydraulic systems. Built with enhanced cellulose media for superior filtration efficiency and rated for 200 PSI operating pressure, these full-flow elements provide reliable contamination control. Perfect for mobile equipment and industrial applications requiring specific thread compatibility and compact design.
Specifications
- Diameter: 3.7″
- Mounting Thread: 1 1/8” – 16
- ∆Pmax: 50 PSID
- Efficiency: ß<4μ(c) = 2 / ß19μ(c) = 75
- Can Color / Imprint: White / Blue
- Seals: Buna-N Gasket Standard
- Caution: Do not use VE Elements on internal combustion engines
Applications
- Suction filters
- On the return circuit, for mounting on the line or on the tank cover
- In-line for low and medium pressure applications
- mowers
- tow trucks
- truck-mounted aerial lifts and cranes
- pavers
- compactors
- wood splitters and chippers
- trenchers
- utility terrain vehicles (UTVs).
Performance Chart
Average Pressure Drop Through Clean Filter Assembly With 150 SUS Oil At 105° F.
Zinga Filter Media Types
Z-Glass Media
Multi-Layered, non-woven glass media that provides the highest levels of depth filtration efficiency and capacity. Higher capacity means longer service life. Coupled with a steel support mesh, Z-Glass can withstand higher differential pressures.
Cellulose Media
Traditional paper based media that provides a nominal level of depth filtration and capacity. Used with petroleum-based fluids only. Some grades of cellulose include a layered glass fiber substrate to provide more efficiency.
AquaZorb Media
Water absorbing cellulose based media designed specifically to absorb and retain free water from petroleum-based fluids. Commonly used in offline systems, AquaZorb will operate until it is fully saturated and ultimately curtail flow through the media. A system by-pass valve and service gauge is recommended when using AquaZorb.
Stainless Steel Mesh
Woven in a variety of precision patterns, stainless steel mesh provides a basic surface type filtration with very low differential pressure. Applications include pump protection and “last chance” valve protection. Stainless steel mesh can be serviced by ultrasonic cleaning. (30: 560µ, 60: 280µ, 100: 141µ, 200:75µ, 200×1400: 10µ)
Compatible Spin-on Filter Heads
VAF Series Spin-On Filter Heads
Flows Up To: 32 GPM (Return) 14 GPM (Suction)
Port Size: 1″ NPTF
Pressure: 250 PSI Max.
Temperature: Up to +250°F
Applications: Petroleum-based fluids; consult factory for synthetic fluids
